The automatic cold heading machine for nuts uses cold drawn disc elements or bar materials to produce a blank of a polished hexagonal nut, which is then threaded to become a polished hexagonal nut.
The nut automatic cold heading machine is horizontal, with workstations arranged horizontally. The entire process of feeding, cutting, clamping, and cold heading is automatically carried out. It has the characteristics of accurate and reliable positioning, easy operation, adjustment, maintenance, and assembly and disassembly, and is an ideal equipment for high-quality and stable production.
Technical parameters of nut cold heading machine
型號
|
制件規格
|
冷鐓滑塊行程
|
工位間距
|
生產率
|
電動機
|
外形尺寸
|
重量
|
Z41-4
|
M3-M4
|
72mm
|
50mm
|
160pec/min
|
3.0kw
|
1200×730×1035mm
|
1200kg
|
Z41-6
|
M4-M6
|
85mm
|
60mm
|
120pec/min
|
4.0kw
|
2395×1430×1230mm
|
3600kg
|
Z41-8
|
M6-M8
|
108mm
|
70mm
|
100pec/min
|
7.5kw
|
2560×1500×1350mm
|
4500kg
|
Z41-10
|
M8-M10
|
108mm
|
80mm
|
90pec/min
|
11kw
|
3200×1800×1500mm
|
5500kg
|
Z41-12
|
M10-M12
|
130mm
|
100mm
|
85pec/min
|
15kw
|
4200×2600×1600mm
|
9200kg
|
Z41-16
|
M14-M16
|
150mm
|
120mm
|
70pec/min
|
18.5kw
|
5020×2800×1800mm
|
1500kg
|
